O型圈/包氟O型圈/星型圈/Y型7
A=美标AS568 B=英标BS1516 C=中国C92标 V.S.P.G=日标 M=公制尺寸 R=法标R
| 代码 |
内径 |
线径 |
代码 |
内径 |
线径 |
代码 |
内径 |
线径 |
代码 |
内径 |
线径 |
|
C92 |
22.40 |
2.65 |
M |
24.00 |
0.70 |
P25.5 |
25.20 |
3.50 |
M |
27.00 |
0.50 |
|
C92 |
22.40 |
3.55 |
M |
24.00 |
0.80 |
M |
25.50 |
0.40 |
M |
27.00 |
0.60 |
|
M |
22.50 |
0.40 |
M |
24.00 |
1.00 |
M |
25.50 |
0.50 |
M |
27.00 |
0.70 |
|
M |
22.50 |
0.50 |
M |
24.00 |
1.50 |
M |
25.50 |
0.60 |
M |
27.00 |
0.80 |
|
M |
22.50 |
0.60 |
M |
24.00 |
2.00 |
M |
25.50 |
0.70 |
M |
27.00 |
1.50 |
|
M |
22.50 |
0.70 |
M |
24.00 |
2.50 |
M |
25.50 |
0.80 |
M |
27.00 |
2.00 |
|
M |
22.50 |
0.80 |
M |
24.00 |
3.00 |
S26 |
25.50 |
2.00 |
M |
27.00 |
2.50 |
|
M |
23.00 |
0.40 |
M |
24.00 |
3.50 |
P26 |
25.70 |
3.50 |
M |
27.00 |
3.00 |
|
M |
23.00 |
0.50 |
M |
24.00 |
4.00 |
C92 |
25.80 |
1.80 |
M |
27.00 |
4.00 |
|
M |
23.00 |
0.60 |
M |
24.00 |
5.50 |
C92 |
25.80 |
2.65 |
M |
27.00 |
5.00 |
|
M |
23.00 |
0.70 |
G25 |
24.40 |
3.10 |
C92 |
25.80 |
3.55 |
M |
27.50 |
0.40 |
|
M |
23.00 |
0.80 |
M |
24.50 |
0.40 |
M |
26.00 |
0.40 |
M |
27.50 |
0.50 |
|
M |
23.00 |
1.00 |
M |
24.50 |
0.50 |
M |
26.00 |
0.50 |
M |
27.50 |
0.60 |
|
M |
23.00 |
1.50 |
M |
24.50 |
0.60 |
M |
26.00 |
0.60 |
M |
27.50 |
0.70 |
|
M |
23.00 |
2.00 |
M |
24.50 |
0.70 |
M |
26.00 |
0.70 |
M |
27.50 |
0.80 |
|
M |
23.00 |
2.50 |
M |
24.50 |
0.80 |
M |
26.00 |
0.80 |
S28 |
27.50 |
2.00 |
|
M |
23.00 |
3.00 |
S25 |
24.50 |
2.00 |
M |
26.00 |
1.00 |
P28 |
27.70 |
3.50 |
|
R-18 |
23.00 |
3.60 |
R-19 |
24.60 |
3.60 |
M |
26.00 |
1.50 |
R-21 |
27.80 |
3.60 |
|
M |
23.00 |
4.00 |
P25 |
24.70 |
3.50 |
M |
26.00 |
2.00 |
A-320 |
27.94 |
5.33 |
|
M |
23.00 |
5.00 |
A-318 |
24.77 |
5.33 |
M |
26.00 |
2.50 |
M |
28.00 |
0.40 |
|
A-317 |
23.16 |
5.33 |
B-19 |
24.99 |
3.53 |
M |
26.00 |
3.00 |
M |
28.00 |
0.50 |
|
A-213 |
23.39 |
3.53 |
M |
25.00 |
0.40 |
M |
26.00 |
3.50 |
M |
28.00 |
0.60 |
|
B-18 |
23.39 |
3.53 |
M |
25.00 |
0.50 |
M |
26.00 |
4.00 |
M |
28.00 |
0.70 |
|
A-119 |
23.47 |
2.62 |
M |
25.00 |
0.60 |
M |
26.00 |
5.00 |
M |
28.00 |
0.80 |
|
A-912 |
23.47 |
2.95 |
M |
25.00 |
0.70 |
R-20 |
26.20 |
3.60 |
M |
28.00 |
1.00 |
|
M |
23.50 |
0.40 |
M |
25.00 |
0.80 |
A-319 |
26.34 |
5.33 |
M |
28.00 |
1.50 |
|
M |
23.50 |
0.50 |
M |
25.00 |
1.50 |
M |
26.50 |
0.40 |
C92 |
28.00 |
1.80 |
|
M |
23.50 |
0.60 |
C92 |
25.00 |
1.80 |
M |
26.50 |
0.50 |
M |
28.00 |
2.00 |
|
M |
23.50 |
0.70 |
M |
25.00 |
2.00 |
M |
26.50 |
0.60 |
M |
28.00 |
2.50 |
|
M |
23.50 |
0.80 |
M |
25.00 |
2.50 |
M |
26.50 |
0.70 |
C92 |
28.00 |
2.65 |
|
S24 |
23.50 |
2.00 |
C92 |
25.00 |
2.65 |
M |
26.50 |
0.80 |
M |
28.00 |
3.00 |
|
V24 |
23.50 |
4.00 |
M |
25.00 |
3.00 |
C92 |
26.50 |
1.80 |
C92 |
28.00 |
3.55 |
|
A-021 |
23.52 |
1.78 |
A-214 |
25.00 |
3.53 |
C92 |
26.50 |
2.65 |
M |
28.00 |
4.00 |
|
C92 |
23.60 |
1.80 |
C92 |
25.00 |
3.55 |
C92 |
26.50 |
3.55 |
M |
28.00 |
5.00 |
|
C92 |
23.60 |
2.65 |
M |
25.00 |
4.00 |
A-215 |
26.57 |
3.53 |
A-216 |
28.17 |
3.53 |
|
C92 |
23.60 |
3.55 |
M |
25.00 |
5.00 |
B-20 |
26.57 |
3.53 |
B-21 |
28.17 |
3.53 |
|
P24 |
23.70 |
3.50 |
M |
25.00 |
6.00 |
A-914 |
26.60 |
2.95 |
A-122 |
28.24 |
2.62 |
|
M |
24.00 |
0.40 |
A-913 |
25.04 |
2.95 |
A-121 |
26.64 |
2.62 |
A-204 |
28.30 |
1.78 |
|
M |
24.00 |
0.50 |
A-120 |
25.07 |
2.62 |
A-023 |
26.70 |
1.78 |
M |
28.50 |
0.40 |
|
M |
24.00 |
0.60 |
A-022 |
25.12 |
1.78 |
M |
27.00 |
0.40 |
M |
28.50 |
0.50 |
●星型圈：内径≥2.9且线径≥1.78时可供货
